Polygonal / Tube Flag Poles (3-18m)

Polygon / Tube Flag Poles (3-18m)

Polygon or tube is manufactured for 3 to 18m Flag poles. See The Giant Flag poles section for larger flag poles.

Technical Specifications

• Pole Height :3m – 18 m.
• Pole Type :Steel pole formed by slip-joint connection of polygonal modules./ Circular section tubular pole.
• Material : St 37 - S235JR - EN 10025 / St 52 - S355JR High Strength Steel
• Ground connection : Anchor Bolt and Base flange for foundation connection (optional with hinge- up to 8m).
• Surface Protection : Hot Dip Galvanised at EN ISO 1416 (galvanised Under ISO Standards) / Electro Galvanised.
• Surface Coating : Electro-static powder coating / Primary + Epoxy
• Bolt / Anchorage : ISO 898. 1 /5.8

Other Specifications:

Statical calculations: EN 40-3-3, ANSI/TIA 222-G, ASCE - 72
Projects according to wind speed 130 km/hr or in compliance with wind speed of 160 km/hr
Raising and lowering mechanism (Highmast) /control panel
Optional aircraft warning lamp
In compliance with the connection of the Lightning Rod
Optional internal halyard system.
Optional automated or hand-driven flag lowering-raising system

Note: The statical project and foundation dimensions are provided by our project team after your order.
Foundation manufacturing and erection services are provided.

Places where they are used
	Airports
	Ports
	Parks and gardens
	Squares
	Industrial Plants and sites
	Sports' fields
	Small scaled sports' fields
	Patios- and private properties
	Military zone
	Memorial
